Description
KX745-69001 - HP System Board (MotherBoard) Socket-LGA1366 Truckee UL8E Pegatron IPMTB-TK for Pavilion Elite
Details
Brand
HP
Weight
8.00 LBS
Form Factor
Micro ATX
CPU Socket Type
LGA 1366
Supported CPU(s)
Intel Core i7 Processor
FSB Speed (Maximum)
4.8 GT/s
Supported CPU Technologies
Enhanced Intel Speedstep Technology, Execute Disable Bit, Hyper-Threading Technology, Idle States, Intel 64 Architecture, Intel Turbo Boost Technology, Intel Virtualization Technology
Chipset
Intel X58 Express
Number of Memory Slot(s)
6
Supported Memory Standard(s)
PC3-8500 (DDR3-1066)
Maximum Installed Memory
24 GB
Expansion Slots
PCI Express x1, PCI Express x16, PCI Express x4
Storage Controller
Serial-ATA 3.0 Gbps
Audio Controller
Realtek ALC888S
Network
Gigabit Ethernet
Connectors/Ports
Audio-In, Audio-Out, FireWire (IEEE 1394), Microphone, RJ-45 (Ethernet), USB 2.0
Additional Information
For HP Desktops:, Pavilion Elite e9100 series, Pavilion Elite e9200 series, Pavilion Elite m9600 series, Pavilion Elite m9700 series
