Description
SRG04 - Intel Xeon D-1653N 8-Core 2.80GHz 12MB Cache Socket FCBGA1667 Processor
Details
Brand
Intel
Weight
2.00 LBS
Processor Type
Server
Series
Xeon D Processor
Core Model Type/ProcNo.
D-1653N
Processor Code Name
Hewitt Lake
Manufacturing Technology
14 nm
# of Cores
8
# of Threads
16
Clock Speed
2.80 GHz
Max Turbo Frequency
3.20 GHz
L3 Cache Size
12 MB
Thermal Power
65 Watts
Max Memory Size
128 GB
Memory Types
DDR4-2400
Maximum Memory Speed
2400 MHz
Memory Channels
2
ECC Memory Supported
Yes
CPU Socket Type
BGA1667
TJUNCTION
105 °C
Package Size
37.5mm x 37.5mm
TCASE
71 °C
Embedded Options Available
No
Scalability
1S
PCI Express
2.0
PCI Express Configurations
x16, x4, x8
Max # of PCI Express Lanes
32
# of USB Ports
8
USB Revision
2.0
Total # of SATA Ports
6
Integrated LAN
4x 10GbE
Max # of SATA 6.0 Gb/s Ports
6
Advanced Technologies
Enhanced Intel SpeedStep Technology, Idle States, Instruction Set 64-bit, Intel 64, Intel Turbo Boost Technology 2.0, Intel Virtualization Technology (VT-x), Intel Virtualization Technology for Directed I/O (VT-d), Intel VT-x with Extended Page Table
Instruction Set Extensions
Intel AVX2
Security & Reliability
Execute Disable Bit, Intel AES New Instructions, Intel OS Guard, Intel Trusted Execution Technology, Secure Key
Product Condition
OEM
Standard Warranty
21 days
