Description
90-MIB8I5-G0ECY0KZ - Asus Desktop Board Intel G31 Express Enhanced SpeedStep Technology Socket T 4GB DDR2 SDRAM
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
Micro ATX
CPU Socket Type
LGA 775
Supported CPU(s)
Intel Celeron Processor, Intel Core2 Duo Desktop Processor, Intel Core2 Extreme Processor, Intel Core2 Quad Processor, Intel Pentium 4 Processor, Intel Pentium D Processor
FSB Speed (Maximum)
1600 MHz
Supported CPU Technologies
Hyper-Threading Technology
Chipset
Intel G31 Express
South Bridge Chipset
Intel ICH7
Number of Memory Slot(s)
2
Number of Memory Channel(s)
2
Supported Memory Standard(s)
PC2-5300 (DDR2-667), PC2-6400 (DDR2-800), PC2-8600 (DDR2-1066)
Maximum Installed Memory
4 GB
Expansion Slots
PCI-E x1, PCI-E x16
Expansion Slots Details
1 x PCIe x16, 1 x PCIe x1, 2 x PCI
Storage Controller
SATA 3.0 Gbps
Audio Controller
VIA VT1708B
Network
Gigabit Ethernet
Connectors/Ports
Audio-In, Audio-Out, Chassis Fan Connector, COM, CPU Fan Connector, PS/2 Keyboard, PS/2 Mouse, RJ-45, USB 1.1, USB 2.0
Connectors/Ports Details
Back Panel I/O Ports, 1 x Parallel, 1 x VGA, 1 x PS/2 Keyboard, 1 x PS/2 Mouse, 1 x LAN(RJ45) port, 4 x USB 2.0/1.1, 1 x COM port, 8 -Channel Audio I/O, , Internal I/O Connectors, 2 x USB connectors support additional 4 USB ports, 1 x Floppy disk dri
