Description
H81M-D-PLUS - Asus Desktop Motherboard Intel H81 Chipset Socket H3 LGA-1150
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
Micro ATX
CPU Socket Type
LGA 1150
Supported CPU(s)
Intel Celeron Processor, Intel Core i3 Processor, Intel Core i5 Processor, Intel Core i7 Processor, Intel Pentium Processor
Supported CPU Technologies
Intel Turbo Boost Technology
Chipset
Intel H81
Number of Memory Slot(s)
2
Number of Memory Channel(s)
2
Supported Memory Standard(s)
PC3-10600 (DDR3-1333), PC3-12800 (DDR3-1600), PC3-8500 (DDR3-1066)
Maximum Installed Memory
16 GB
Expansion Slots
PCI-E 2.0 x1, PCI-E x16
Storage Controller
SATA 3.0 Gbps, SATA 6.0 Gbps
Audio Controller
Realtek ALC887
Network
Gigabit Ethernet
Connectors/Ports
Audio-In, Audio-Out, Chassis Fan Connector, COM, CPU Fan Connector, D-Sub, DVI-D, Parallel, PS/2 Keyboard, PS/2 Mouse, RJ-45, Serial, USB 2.0, USB 3.1
Connectors/Ports Details
Back I/O Ports, 1 x PS/2 keyboard (purple), 1 x PS/2 mouse (green), 1 x DVI, 1 x D-Sub, 1 x LAN (RJ45) port(s), 2 x USB 3.1 Gen 1 (blue), 2 x USB 2.0, 1 x Parallel port(s), 3 x Audio jack(s), , Internal I/O Ports, 1 x USB 3.1 Gen 1 connector(s) suppo
Warranty Information
8
