Description
P8Z68-V-PRO/GEN3 - Asus Desktop Motherboard Intel Socket H2 LGA-1155 ATX 1 x Processor Support 32GB DDR3 SDRAM Maximum RAM SLI, CrossFireX Support Serial ATA/300, Serial ATA/600 Yes Controller No 3 x PCIe x16 Slot 2 x USB 3.0 Port Yes
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
ATX
CPU Socket Type
LGA 1155
Supported CPU(s)
Intel Celeron Processor, Intel Core i3 Processor, Intel Core i5 Processor, Intel Core i7 Processor, Intel Pentium Processor
Supported CPU Technologies
Intel Turbo Boost Technology
Chipset
Intel Z68 Express
Number of Memory Slot(s)
4
Number of Memory Channel(s)
2
Supported Memory Standard(s)
PC3-10600 (DDR3-1333), PC3-12800 (DDR3-1600), PC3-14900 (DDR3-1866), PC3-8500 (DDR3-1066)
Maximum Installed Memory
32
Expansion Slots
PCI-E 2.0 x1, PCI-E 2.0 x16
Expansion Slots Details
2 x PCIe 3.0/2.0 x16 (x16 or dual x8) *1, 1 x PCIe 2.0 x16 (x4 mode, black) *2, 2 x PCIe x1, 2 x PCI
Storage Controller
SATA 3.0 Gbps, SATA 6.0 Gbps
Audio Controller
Realtek ALC892
Network
WLAN
Connectors/Ports
Audio-In, Audio-Out, Chassis Fan Connector, CPU Fan Connector, DVI, HDMI, PS/2 Keyboard, PS/2 Mouse, RJ-45, USB 2.0, USB 3.1
